POS machines

Processor :Intel Apollo Lake N3350; Intel Apollo Lake J3455

Storage Device :M.2 connector (SATA Signal Only) x 1

System Memory:DDR3L SO-DIMM x 1, max. 8GB

OS Support :Windows 10 IoT

Power Supply :12V / 40W

Display & Touch : LCD Display 15.6″ TFT LCD

Resolution : 1366 x 768

Touch Function : True-flat PCAP touch with multi-touch support (IP65 on front panel)

I/O & Expansion :Audio Buzzer x 1; Optional internal 2W speaker x 1

CR Port 1, control 2 CR via optional Y-cable

Display Port :VGA x 1, 12V support for Posiflex monitors

Extension Slot :M.2 x 1

LAN Port :10 / 100 / 1000 Mb x 1

Parallel Port:1, via optional conversion cable through service window

Powered USB Port :Optional 24V x 1 + 12V x 3 via GEN8 base

PS/2 Port :1, via optional conversion cable through service window

Serial Port :4, DB9 x 3 + RJ50 x 1, 5V/12V support on all COM ports

Standard USB Port :5, USB 3.0 x 2+ USB 2.0 x 2 (on I/O plate) + USB 2.0 x 1 (on the top)

Built-in Option :WiFi USB WiFi dongle

Physical Characteristics :Dimension (W x D x H in mm) :372 x 252.7 x 291.4

Environment :Operating Condition 0°C – 50°C, 20%RH – 90%RH (Equipped with SSD)

Storage Condition -20°C – 70°C, 10%RH – 90%RH

Attachment Options :Line Display 2 x 20 rear-mount VFD customer line display, 2 x 20 rear-mount LCD customer line display, 7-inch color LCD graphical line display.

POS Monitor:Non-touch TFT USB LCD: 7-inch/9.7-inch

More Peripherals :MSR; iButton; RFID; Fingerprint Sensor; Keypad
